The approaches that DynamoRIO and Pin take to

instrumentation are fundamentally different.  Pin's

interface is not so different from tools that modify the

original code, such as ATOM, Dyninst, Vulcan, or Detours.

The only instrumentation option in Pin is to insert a

callout or trampoline to instrumentation code at a

particular point in the application's code stream.  The

application code stream itself cannot be modified directly.

Pin does use its code cache to improve over non-code-cache

tools that modify original application code in two respects:

code discovery and transparency.  The code cache design

allows for incremental dynamic discovery of code, making it

simple to examine all code that is executed, while

non-code-cache tools must statically (or at load time)

determine which code to instrument based on the application

binary and library files.  The code cache also eliminates

safety issues of modifying variable-length IA-32/AMD64 code:

direct modification by inserting a 5-byte jump instruction

can overwrite an entry point midway through those 5 bytes,

as well as suffer from races with multiple threads and

complications if those 5 bytes are later examined or

modified by the application (essentially, the displaced 5

bytes are a "miniature code cache" that incur all the same

complications as a regular code cache).

DynamoRIO leverages its code cache to provide a much broader

interface.  DynamoRIO allows modification of the runtime

code stream of the application: modifying, inserting, or

removing individual instructions.  This is in stark contrast

to Pin's observe-and-callout model.  DynamoRIO's interface

is only possible with a code cache, and it takes full

advantage of the cache's power.  Not only does this general

interface let DynamoRIO support non-observational-only uses,

such as optimization or translation, but it also gives full

control over instrumentation to the tool writer.  While Pin

does automatically inline and optimize simple callouts, the

client has little control or guarantee over the final

performance, and a minor change in the instrumentation

routine can have an order of magnitude impact in performance

if it prevents inlining.

For a real-world example, consider the PiPA memory profiler

and cache simulator:

Implemented as a DynamoRIO tool, PiPA improved the

performance of the Pin dcache tool by a factor of 3.27x.

Implemented in Pin the speedup was only 2.6x, due to the

inability to fully optimize the instrumentation.

As requested I have gathered updated numbers for the bbcount

comparison using the new Pin release 22117, which has

improved inlining support.  Several benchmarks such as

perlbmk, crafty, and eon improve noticeably.  The harmonic

means are now 226% (a 5% improvement from 231%), 233%, and

185%, respectively.
